System 110

Metal suspension system for metal planks and tiles hook-on mounting

Ceiling system 110

System	Metal concealed hook-on system
suitable for	Metal planks and tiles, each removable
Characteristic	Symmetrical layout with butt joints

Components comply with the valid DIN-EN standards.

Quantities are estimated based on large ceiling areas. Modules connecting to walls are not considered in this statement. For smaller rooms the requirement of material can be considerably higher. Distances to be agreed with panel manufacturer. No responsibility is taken for this statement.

item	order no.	description	thickness	length	packing unit	quantity per sqm, length of tiles A*
						1.200 mm	1.500 mm	1.800 mm	2.000 mm
1	1/30	nonius hanger upper part	1,00 mm	on demand	100 pcs	0,70 pcs*	0,70 pcs*	0,70 pcs*	0,70 pcs*
2	1/14	safety pin	2,50 mm	60 mm	100 pcs	1,40 pcs*	1,40 pcs*	1,40 pcs*	1,40 pcs*
3	1/37 C 62	nonius hanger lower part	1,25 mm	122 mm	100 pcs	0,70 pcs*	0,70 pcs*	0,70 pcs*	0,70 pcs*
4	DP 16	primary runner	0,75 mm	4.000 mm	32 Meter	0,84 Meter	0,84 Meter	0,84 Meter	0,84 Meter
5	1/104	splice	0,50 mm	110 mm	100 pcs	0,21 pcs	0,21 pcs	0,21 pcs	0,21 pcs
6	WA 16	wall anchor	1,00 mm	50 mm	100 pcs	on demand	on demand	on demand	on demand
7	AS 60	connecting bracket	0,60 mm	40 mm	100 pcs	0,70 pcs	0,56 pcs	0,46 pcs	0,42 pcs
8	AS 11	hook-on profile	1,25 mm	4.000 mm	40 Meter	0,84 Meter	0,67 Meter	0,56 Meter	0,50 Meter
9	AS 15	splice	1,25 mm	100 mm	100 pcs	0,21 pcs	0,17 pcs	0,14 pcs	0,13 pcs
10	AS 30	wall connector	2,00 mm	100 mm	100 pcs	on demand	on demand	on demand	on demand
11	AS 45	hexagonal bolt	M6	20 mm	500 pcs	1,80 pcs	1,65 pcs	1,55 pcs	1,50 pcs
	AS 50	nut			100 pcs	1,80 pcs	1,65 pcs	1,55 pcs	1,50 pcs
	AS 55	washer			1.000 pcs	1,80 pcs	1,65 pcs	1,55 pcs	1,50 pcs
12	DP 52	hold-down perimeter angle trim	0,75 mm	3.000 mm	60 Meter	on demand	on demand	on demand	on demand
13	1/187	hold-down spring	0,50 mm	48 mm	500 pcs	on demand	on demand	on demand	on demand

*We recommend at least one hanger per 1,5 sqm ceiling area.
